Basic Info.
Model NO.
YM41 H frame solid tire press
Structure
Vertical
Power Source
Hydraulic Press
Type
Simple Disassembly
Automatic
Automatic
Standard
Standard
Certification
CE, ISO
Condition
New
Product Name
Forklift Solid Tire Press Machine
Application
Forklift Solid Tire, Truck Tire, Industrial Tyres
Usage
Dismounting and Mounting The Wheel Rim
Worktable
1000*800
Stroke
500
Model
80t,100t,120t,150t,160t,200t
Frame
H Frame Solid Tire Changer
Tyre Size
8"-24"
Tools
Provided
Certificate
Ce/ISO
Transport Package
Plastic Film and Plywood Box
Specification
2.0T
Trademark
Zhongyou
Origin
Tengzhou City, Shandong Prov., China
HS Code
8479899990
Production Capacity
50 Sets/Month
Packaging & Delivery
Package Size
1000.00cm * 1000.00cm * 1000.00cm
Package Gross Weight
1000.000kg
Product Description
Heavy duty Construction Solid Tyre Changer/dismounting Hydraulic forklift solid tire press machine
Description for Forklift solid tire press machine
Forklift tire press is a kind of solid pressure tire changers
machine, used to assemble and disassemble with ring
rims and tires. It is mainly used for all kinds of solid tyre
disassembly and tire pressure.
| Specification | Nuit | YM-80 | YM-100 | YM-120 | YM-160 | YM-200 |
| Nominal force | kN | 800 | 1000 | 1200 | 1600 | 2000 |
| Max pressure | Mpa | 31.5 | 31.5 | 31.5 | 31.5 | 31.5 |
| Opening height | mm | 700 | 800 | 900 | 1000 | 1100 |
| Effective stroke | mm | 400 | 500 | 400 | 550 | 600 |
| Worktable size | mm | 1000*800 | 1000*800 | 1000*800 | 1000*800 | 1200*800 |
| Motor power | Kw | 3 | 4 | 4 | 5.5 | 5.5 |
All the parameters can be made according to your requirement.
1.The hydraulic cylinder is Zhongyou brand(our independent research and development brand)
2.The motor is China famous brand,other brand like Siemens etc is also available,the phase and herze can be made according to your local place
3.The hydraulic press is integral castings,the overall strength is high
4.Our factory is the first manufacturer who developed hydraulic cylinder without oil leakage technology in Tengzhou city.
How to Use the solid tire press machine?
1.Choose a good tooling correctly,2.Put the mould on the work table,
3.Put the wheel on the mould, handling pressure head to Press the die on the tire
4.Finally with the boot ring loaded.
Different types of tyres and wheels need different tooling, the user to install the tire before the selection of tooling, then the disassembly and assembly operations, it will be very convenient and quick. According to the motion mode and the size of the machine, the machine can be divided into manual press and electric press, which is generally suitable for large tonnage forklift truck or truck tire.
